Home > Stainless Steel > Marine Grade Stainless Steel Pipe
Welcome to Tun Pipes, your trusted partner for marine-grade stainless steel pipe in Naypyidaw. We understand the critical demands of the maritime environment, which is why we provide robust piping solutions designed to withstand the unique challenges of saltwater and coastal conditions. Sourced from trusted materials and crafted with precision, our pipes offer the longevity and reliability that your marine projects require. When you choose Tun Pipes, you are selecting a dependable supplier committed to supporting Myanmar’s maritime and industrial growth with products you can count on.
The composition of marine-grade stainless steel pipe includes a careful blend of chromium, nickel, and molybdenum. This specific formulation significantly increases resistance to pitting and corrosion, especially in chloride-rich sea air and saltwater. The material also possesses excellent mechanical properties, including high tensile strength and impressive durability. These characteristics allow the pipes to maintain their structural integrity under high pressure and the constant stresses of marine operations, providing a safe and long-lasting solution.
| Size | 1/8″(10.3mm) to 12″(323.8mm) |
| Grades | TP -304, 316,316L, |
| Schedule | 5/5S,10/10S,20/20S,40/40S,80/80S,120/120S,160/160S according to ANSI B36.19/36.10 |
| Marine Grade Stainless Steel Pipe Applications | marine fittings, marine fasteners, and marine structures |
| Finish | Satin Finish(180#.240#.320#).,Bright Finish(400#,600#,mirror),Mill Finish(2B),Hairline-Finish(HL/Brushed),Ti-gold, Glossy matt,dull and so on. |
| PIPE SIZE | OD IN INCHES | A.S.A. Pipe Schedules | |||||||||||||||
| 5s | 5 | 10s | 10 | 20 | 30 | 40s & Std. | 40 | 60 | 80s & E.H. | 80 | 100 | 120 | 140 | 160 | DBL E.H. | ||
| 1/8 | .405 | .035.1383 | .049.1863 | .049.1863 | .068.2447 | 068.2447 | 0.95.3145 | 0.95.3145 | |||||||||
| 1/4 | .540 | .049.2570 | .065.3297 | .065.3297 | .088.4248 | 088.4248 | .119.5351 | .119.5351 | |||||||||
| 3/8 | .675 | .049.3276 | .065.4235 | .065.4235 | .091.5676 | .091.5676 | .126.7338 | .126.7338 | |||||||||
| 1/2 | .840 | .065.5383 | .065.5383 | .083.6710 | .083.6710 | .109.8510 | .109.8510 | .1471.088 | .1471.088 | .1871.304 | .2941.714 | ||||||
| 3/4 | 1.050 | .065.6838 | .065.6838 | .083.8572 | .083.8572 | .1131.131 | .1131.131 | .1541.474 | .1541.474 | .2181.937 | .3082.441 | ||||||
| 1 | 1.315 | .065.8678 | .065.8678 | .1091.404 | .1091.404 | .1331.679 | .1331.679 | .1792.172 | .1792.172 | .2502.844 | .3583.659 | ||||||
| 1-1/4 | 1.660 | .0651.107 | .0651.107 | .1091.806 | .1091.806 | .1402.273 | .1402.273 | .1912.997 | .1912.997 | .2503.765 | .3825.214 | ||||||
| 1-1/2 | 1.900 | .0651.274 | .0651.274 | .1092.085 | .1092.085 | .1452.718 | .1452.718 | .2003.631 | .2003.631 | .2814.859 | .4006.408 | ||||||
| 2 | 2.375 | .0651.604 | .0651.604 | .1092.638 | .1092.638 | .1543.653 | .1543.653 | .2185.022 | .2185.022 | .3437.444 | .4369.029 | ||||||
| 2-1/2 | 2.875 | .0832.475 | .0832.475 | .1203.531 | .1203.531 | .2035.793 | .2035.793 | .2767.661 | .2767.661 | .37510.01 | .55213.70 | ||||||
| 3 | 3.500 | .0833.029 | .0833.029 | .1204.332 | .1204.332 | .2167.576 | .2167.576 | .30010.25 | .30010.25 | .43714.32 | .60018.58 | ||||||
| 3-1/2 | 4.000 | .0833.472 | .0833.472 | .1204.973 | .1204.973 | .2269.109 | .2269.109 | .31812.51 | .31812.51 | .63622.85 | |||||||
| 4 | 4.500 | .0833.915 | .0833.915 | .1205.613 | .1205.613 | .23710.79 | .23710.79 | .28112.66 | .33714.98 | .33714.98 | .43719.01 | .53122.51 | .67427.54 | ||||
| 4-1/2 | 5.000 | .24712.53 | .35517.61 | .71032.53 | |||||||||||||
| 5 | 5.563 | .1096.349 | .1096.349 | .1347.770 | .1347.770 | .25814.62 | .25814.62 | .37520.78 | .37520.78 | .50027.04 | .62532.96 | .75038.55 | |||||
| 6 | 6.625 | .1097.585 | .1097.585 | .1349.290 | .1349.290 | .28018.97 | .28018.97 | .43228.57 | .43228.57 | .56236.39 | .71845.30 | .86453.16 | |||||
| 7 | 7.625 | .30123.57 | .50038.05 | .87563.08 | |||||||||||||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Marine Grade Stainless Steel Pipes from Tun Pipes and Tubes ensures high-quality materials with excellent corrosion resistance and durability. Our products are tailored to meet diverse industry standards, offering reliability and versatility for various applications. Our commitment to customer service and timely delivery makes us a trusted supplier.
Tun Pipes and Tubes, one of the largest suppliers of Marine Grade Stainless Steel Pipes in Naypyidaw, Myanmar, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
| Marine Grade Stainless Steel Pipe Grades | UNS | Si | Mn | S | C | P | Cr | Ni | Mo |
|---|---|---|---|---|---|---|---|---|---|
| TP304 | S30400 | 1 | 2 | 0.03 | 0.08 | 0.045 | 18.0-20.0 | 8.0-11.0 | – |
| TP304L | S30403 | 1 | 2 | 0.03 | 0.035 | 0.045 | 18.0-20.0 | 8.0-13.0 | – |
| Material | Tensile Strength | Yield Strength | Heat | Temperure | Elongation %, Min |
|---|---|---|---|---|---|
| Ksi (MPa), Min. | Ksi (MPa), Min. | Treatment | Min. | ||
| º F(º C) | |||||
| Stainless Steel | 75(515) | 30(205) | Solution | 1900 (1040) | 35 |
| Nominal | SS Square Pipe Schedule 5 | SS Square Pipe Schedule 10 | SS Square Pipe Schedule 40 | |||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Inch | MM | Wt./MM | Kg./M | Kg./Ft | Wt./MM | Kg./M | Kg./Ft | Wt./MM | Kg./M | Kg./Ft |
| 1 / 2 | 21 | 1.65 | 0.801 | 0.244 | 2.11 | 0.999 | 0.305 | 2.77 | 1.270 | 0.387 |
| 3 / 4 | 21.30 | 1.65 | 1.020 | 0.311 | 2.11 | 1.280 | 0.390 | 2.87 | 1.680 | 0.512 |
| 1 | 26.70 | 1.65 | 1.290 | 0.393 | 2.77 | 2.090 | 0.637 | 3.38 | 2.500 | 0.762 |
| 1 1 / 4 | 33.40 | 1.65 | 1.650 | 0.503 | 2.77 | 2.690 | 0.820 | 3.56 | 3.380 | 1.030 |
| 1 1 / 2 | 42.20 | 1.65 | 1.900 | 0.579 | 2.77 | 3.110 | 0.948 | 3.68 | 4.050 | 1.230 |
| 2 | 48.30 | 1.65 | 3.340 | 0.728 | 2.77 | 3.920 | 1.200 | – | – | – |
| 2 1 / 2 | 73.00 | 2.11 | 3.690 | 1.130 | 3.05 | 5.260 | 1.600 | – | – | – |
| 3 | 88.90 | 2.11 | 4.510 | 1.380 | 3.05 | 6.450 | 1.970 | – | – | – |
| 3 1 / 2 | 101.60 | 2.11 | 5.190 | 1.580 | 3.05 | 7.400 | 2.260 | – | – | – |
Yes, we offer custom sizes for Marine Grade Stainless Steel Pipes to meet your specific requirements. Our team at Tun Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@tunpipes.com.
You’ll find Marine Grade Stainless Steel Pipes being widely utilized in shipbuilding, offshore oil and gas platforms, desalination units, seawater piping systems, heat exchangers, and ballast systems. They’re also a popular choice for coastal architectural structures, chemical processing, and marine equipment manufacturing. Thanks to their exceptional corrosion resistance, mechanical strength, and long service life, these pipes guarantee safe and efficient performance in the demanding conditions of marine and industrial environments.
