Nestled in the heart of Naypyidaw, Myanmar, Tun Pipes stands as a leading manufacturer and supplier, providing industry with precision-crafted stainless steel perforated tubing. We understand that the right components are the backbone of any successful project. That’s why we are dedicated to producing tubing solutions that are not only robust and reliable but also tailored to meet the specific demands of our clients, ensuring your operations benefit from superior performance and durability every step of the way.
The composition of our stainless steel perforated tubing typically leans on grades like 304 or 316, which are celebrated for their excellent corrosion resistance. These alloys are carefully processed to achieve impressive mechanical properties, including high tensile strength and good durability, allowing the tubing to perform reliably under significant pressure and in challenging environments. This inherent toughness ensures a long service life, providing a dependable solution for demanding industrial tasks where failure is not an option.
| ASTM | ASTM A249, A269, A270 |
| OD. | 1/8” NB to 24” NB, 1/4” OD to 24” OD sizes stainless steel welded tubes also available |
| Thickness | 0.2mm to 15mm |
| Hole size | 3mm dia on a 6mm pitch |
| Opening diameter | 0.2mm to 100mm |
| Material | SS 304, SS 304L,SS 316,SS 316L, SS201 |
| Finish | BA Finish inside and outside, Perforated finish inside and outside |
| Type | As Welded, EFW, ERW, Seamless, Semi Seamless, Bead Removed |
| Mill Test Certificate | EN10204 3.1 |
| Packing | Sleeved, Ends Capped, Wooden Boxed |
| STAINLESS STEEL Perforated TUBE GRADES | UNS | C | Mn | P | S | Si | Cr | Ni | Mo | Ti | Nb | N |
| TP304 | S30400 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | ||||
| TP304L | S30403 | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-13.0 | ||||
| TP316 | S3160 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | |||
| TP316L | S31603 | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| Material | Heat | Temperure | Tensile Strength | Yield Strength | Elongation %, Min |
| Treatment | Min. | Ksi (MPa), Min. | Ksi (MPa), Min. | ||
| º F(º C) | |||||
| TP304 | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
| TP304L | Solution | 1900 (1040) | 70(485) | 25(170) | 35 |
| TP316 | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP316L | Solution | 1900(1040) | 70(485) | 25(170) | 35 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| GRADE | UNS NO | DIN/WERKSTOFF |
|---|---|---|
| 304 | S30400 | 1.4301 |
| 304L | S30403 | 1.4306 |
| 316 | S31600 | 1.4436 |
| 316L | S31603 | 1.4404 |
Choosing Stainless Steel Perforated Tubing from Tun Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Tube is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.
Tun Pipes and Tubes, one of the largest suppliers of Stainless Steel Perforated Tubing in Naypyidaw, Myanmar, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
| SIZE OD | NOMINAL WALL THICKNESS | OUTSIDE DIAMETER TOLERANCE | LENGTH TOLERANCE | WALL THICKNESS TOLERANCE | ||||
|---|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (%) |
| ½ | 12.7 | 0.065 | 1.65 | +/-0.005 | +/-0.13 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| ¾ | 19.1 | 0.065 | 1.65 | +/-0.005 | +/-0.13 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 1 | 25.4 | 0.065 | 1.65 | +/-0.005 | +/-0.13 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 1½ | 38.1 | 0.065 | 1.65 | +/-0.008 | +/-0.20 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 2 | 50.8 | 0.065 | 1.65 | +/-0.008 | +/-0.20 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 2½ | 63.5 | 0.065 | 1.65 | +/-0.010 | +/-0.25 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 3 | 76.2 | 0.065 | 1.65 | +/-0.010 | +/-0.25 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 4 | 101.6 | 0.083 | 2.11 | +/-0.015 | +/-0.38 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 6 | 152.4 | 0.109 | 2.77 | +/-0.030 | +/-0.76 | +1, -0 | +25.4, -0 | +/-10.0% |
Yes, we offer custom sizes for Stainless Steel Perforated Tubing to meet your specific requirements. Our team at Tun Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@tunpipes.com.
Stainless Steel Perforated Tubing is widely used across many industries because of its functionality and adaptability. In construction and architecture, it’s often found in decorative panels, facades, and systems for controlling sound. In industrial settings, it plays a role in filtration, ventilation, exhaust systems, and protective enclosures. The automotive industry utilizes it in mufflers, grilles, and sound suppression systems, while in the oil and gas sector, it aids in sand control and fluid distribution. Plus, it’s commonly used in food processing and chemical processing applications, showcasing its broad appeal and utility.
